iPro - Outdoor floodlight - Warm white LED - integrated dimmable DALI power supply - Flood optic - 31.1W 2920lm - 3000K

Product Information

  • Material: Aluminium
  • Size (mm): 192x192x200, Weight (kg): 5.65
  • Design: Mario Cucinella

Available colours

Lighting parameters

Electrical parameters

  • Dimmable Electronic Control gear included
  • Control: DALI-2
  • Ballast losses [W]: 3.1
  • N° lamps assembly: 1
  • Operating ambient temperature range: da -25°C a 40°C.
  • Power Factor: See installation instructions
  • Inrush Current: 10 A / 200 µs
  • Circuit Braker:
    B10A: 18 luminaires
    B16A: 30 luminaires
    C10A: 31 luminaires
    C16A: 51 luminaires
  • Perc Min Dimmer: 1
  • Overvoltage Protection: 5kV Common mode & 4kV Differential mode

Technical Specifications

Installation information

  • Installation: Ground, wall or ceiling installation using special bracket. Secure using screw anchors for concrete, cement and solid brick.
  • Environment: Outdoor
  • Wiring: Luminaire with DALI dimmable electronic power supply (220 - 240V ac, 50/60 Hz).
Accessories (51)
  • PA03

    BLE-DALI 32 interface for outdoor use
    Size (mm): 230x113x67
    • 00 Indeterminate
  • X478

    BLE-DALI 4 Interface - 2.4GHz - 4 DALI addresses max - Integrated beacon - VIN = 220-240Vac - dim. 235x80x68 mm
    Size (mm): 235x80x67
    • 00 Indeterminate
  • 1154

    Prismatic diffuser glass
    • 24 Clear transparent
  • BZ77

    Accessory support frame - To be used for the installation of accessories
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • BZ80

    Refractor for elliptical distribution
    • 24 Clear transparent
  • BZ85

    Protection grille
    • 13 Steel
  • BZ87

    Single directional fin
    • 04 Black
  • BZ88

    Visor
    • 04 Black
  • 1205

    Pole for burial L=5600 diam. 102 mm
    Size (mm): ø102x5600
    • 15 Grey
  • 1274

    Cylindrical pole for burial D 120 mm H 10000
    Size (mm): ø120x10000
    • 15 Grey
  • 1287

    Pole for burial L=8000 mm D=120 mm
    Size (mm): ø120x8000
    • 15 Grey
  • 1288

    Tapered pole h=10000 mm D=120/194 mm thickness 3 mm (D194) and 4 mm (D120)
    Size (mm): ø120x10000
    • 15 Grey
  • 1289

    Pole with base plate L=7000 D=120 mm
    Size (mm): ø120x7000
    • 15 Grey
  • 1290

    Tapered pole with plate h=9000 mm D=120/194 mm thickness 3 mm (D194) and 4 mm (D120)
    Size (mm): ø120x9000
    • 15 Grey
  • 1291

    Pole for burial L=5600 mm D=120 mm thickness 3 mm
    Size (mm): ø120x5600
    • 15 Grey
  • 1292

    Pole with base plate L=5000 mm D=120 mm and thickness 3 mm
    Size (mm): ø120x5000
    • 15 Grey
  • 1344

    Pole with base plate L=5000 D=102 mm
    Size (mm): ø102x5000
    • 15 Grey
  • 1542

    Pole for burial L=6800 d=102 mm H=6000 mm
    Size (mm): ø102x6800
    • 15 Grey
  • 1543

    Pole for burial L=8000 d=102 mm H=7000 mm
    Size (mm): ø102x8000
    • 15 Grey
  • 1544

    Pole for burial L=9000 d=102/127 mm H= 8000 mm
    Size (mm): ø102x8000
    • 15 Grey
  • 1545

    Pole for burial L=10000 mm d=120/194 mm H= 9000 mm
    Size (mm): ø120x10000
    • 15 Grey
  • 1547

    Pole with base plate D=120/194 mm H=9000 mm
    Size (mm): ø120x9000
    • 15 Grey
  • 1597

    Pole with plate d=102 mm H=6000 mm
    Size (mm): ø159x6000
    • 15 Grey
  • 1598

    Pole with plate d=102 mm H=7000 mm
    Size (mm): ø159x7000
    • 15 Grey
  • 1599

    Pole with plate d=102 mm H=8000 mm
    Size (mm): ø159x8000
    • 15 Grey
  • X730

    Buried pole H= 5600 (h=5000 above ground), Ø 159-102mm with twin access cover 310x95mm
    Size (mm): ø102x5600
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X731

    Buried pole H= 7800 (h=7000 above ground), Ø 159-102mm with twin access cover 310x95mm
    Size (mm): ø102x7800
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X732

    Buried pole H= 9.800 (h=9000 above ground), Ø 194-120mm with twin access cover 310x95mm
    Size (mm): ø120x9800
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X733

    Buried pole H= 12800 (out of the ground h=12000), Ø 219-120mm with twin access cover 310x95mm
    Size (mm): ø120x13000
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X734

    Pole with plate H= 5000, Ø 159-102mm with twin access cover 310x95mm.
    Size (mm): ø102x5000
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X735

    Pole with plate H= 7.000, Ø 159-102mm with twin access cover 310x95mm
    Size (mm): ø102x7000
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X736

    Pole with plate H= 9.000, Ø 194-120mm with twin access cover 310x95mm
    Size (mm): ø120x9000
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X737

    Pole with plate H= 120000 Ø219-120mm with twin access cover 310x95mm.
    Size (mm): ø120x12000
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6012

    Aluminium flange for installation on poles ø 120 mm - for 1 projector MaxiWoody ø260-ø315-ø380/ iPro □192mm
    Size (mm): 149x180x135
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6013

    Aluminium flange for installation on poles ø 120 mm - for 2 projectors MaxiWoody ø260-ø315-ø380/ iPro □192mm
    Size (mm): 156x180x135
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6014

    multiple support for 2 floodlights
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6015

    multiple support for 3 floodlights
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6111

    Aluminium flange for installation on poles ø 102 mm - for 1 projector MaxiWoody ø260-ø315-ø380/ iPro □192mm
    Size (mm): 119x165
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6112

    Aluminium flange for installation on poles ø 102 mm - for 2 projectors MaxiWoody ø260-ø315-ø380/ iPro □192mm
    Size (mm): 126x165
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6161

    Counter flange ø102mm
    Size (mm): ø102
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 6162

    Counter flange ø120mm
    Size (mm): ø120
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • BZ91

    L-shaped bracket for installation on large frames
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • BZM5

    Applique clip
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X568

    Horizontal Arm L=489mm - for Ø102mm poles
    Size (mm): 489x65x63
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X570

    Horizontal Arm L=947mm - for Ø102mm poles
    Size (mm): 947x65x63
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X569

    Horizontal Arm L=489mm - for Ø120mm poles
    Size (mm): 499x65x63
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X571

    Horizontal Arm L=947mm - for Ø120mm poles
    Size (mm): 947x65x63
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X572

    Accessory for down installation
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X657

    Interface for installation on arm - For Agorà, Maxiwoody, iPro projectors
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • X738

    Steel flange for installation on cylindrical-conical poles with twin access covers diameter Ø102mm and Ø120mm - for 1 Agorà Compact, Agorà Slim, Maxiwoody and iPro spotlight.
    Size (mm): 71x115
    • 01 White
    • 04 Black
    • 15 Grey
    • F5 Rust brown
  • 1880

    Junction box - Suitable for poles with ø≥120mm
    Size (mm): 120x80x50
    • 00 Indeterminate
