iWay round belongs to iWay bollard round

BW77

Updating Product Data...

Photometric configuration only available on screens above 1024px

Select a combination of accessories to download
specific product data sheets and photometric curves.

iWay round - Bollard D=170mm H=610mm Warm White Led with DALI electronic ballast and symmetrical optic - 12.4W 1180lm - 3000K

Product Information

  • Material: extruded aluminium
  • Size (mm): ø170x610, Weight (kg): 7.02
  • Design: Jean-Michel Wilmotte

Available colours

Lighting parameters

Electrical parameters

  • Electronic Control gear included
  • Control: DALI-2
  • Ballast losses [W]: 1.4
  • N° lamps assembly: 1
  • Operating ambient temperature range: da -30°C a 50°C.
  • Power Factor: See installation instructions
  • Inrush Current: 9.2 A / 25 µs
  • Circuit Braker:
    B10A: 27 luminaires
    B16A: 44 luminaires
    C10A: 45 luminaires
    C16A: 74 luminaires
  • Perc Min Dimmer: 5
  • Overvoltage Protection: 6kV Common mode & 6kV Differential mode

Technical Specifications

Installation information

  • Installation: Can be installed directly using Fischer fixings (on the ground), or using a fixing base and fixing plate with clamps coated in Dacromet, for an additional guarantee against corrosion (to be ordered separately).
  • Environment: Outdoor
  • Wiring: Inside the luminaire is the removable component-holding plate, secured to the box with captive screws and the quick coupling for the electrical connections. DALI Electronic control gear. Complete with rubber output cable A07RN-F 4x1mm L=1700 mm.
Accessories (10)
  • X478

    BLE-DALI 4 Interface - 2.4GHz - 4 DALI addresses max - Integrated beacon - VIN = 220-240Vac - dim. 235x80x68 mm
    Size (mm): 235x80x67
    • 00 Indeterminate
  • X023

    Screen for asymmetrical 180° emission
    • 04 Black
  • X087

    Satin-finished screen
    • 65 Nitric
  • B513

    Counter-plate with anchor bolts
    Size (mm): ø275x179
    • 00 Indeterminate
  • X529

    Support plate for Y-connector and BLE-Dali 4
    Size (mm): 223x98x15
    • 00 Indeterminate
  • B915

    IP68 box for multiple connections - dim. 135x82x70h
    Size (mm): 135x82x70
    • 04 Black
  • BZN7

    Y connector with 5 poles IP68 - For the connection of the DMX or DALI signal cable and power supply cable
    • 00 Indeterminate
  • X188

    2-way junction connector - IP68
    Size (mm): ø23
    • 00 Indeterminate
  • X189

    4-way junction connector - IP68
    Size (mm): 80x54x28
    • 00 Indeterminate
  • X562

    2-way IP68 male/female junction connector - 5 poles - 250/400V - DALI
    • 04 Black
