Street pole-top 416x211mm

All Street

Product Details

  • Urban lighting system intended for use with LED light sources.
  • Installation on poles with side arms or whip-like terminal parts from ø 42 to ø 76 mm.
  • Optical compartment in die-cast aluminium; hot dip galvanised steel tubular arms; sodium-calcium tempered protection glass, with 5 mm thickness.
  • No upwards dispersion of the luminous flux.
  • Adjustable optical compartment.
  • High visual comfort.
  • High yield optics (Opti Smart Lens) (with polymer optic lenses and uniform light distribution).
  • No photo-biological risks . This luminaire is in the “Exempt Group” (no risk linked to infra-red, blue light and UV radiation) in accordance with the EN 62471:2008 standard.
  • The Street luminaire including terminal can be programmed as DALI-MIDNIGHT-ON / OFF via the interface used to set the luminous flux or via NFC.
  • The Street luminaire supplied with outgoing cable but terminal not included can be programmed only with the MIDNIGHT (NO DALI) profile via NFC.
  • Over voltage surge protection: 10kV in Common Mode (CM), 6kV in Differential Mode (DM).
  • All external screws used are in A2 Compositions single arm L=900 with intermediate arms L=900 (double installation) pole with single arm pole with double arm tapered curved pole with intermediate fitting tapered curved pole Pole-top Shaped poles double pole-top single pole-top triple pole-top wall attachment Arms iguzzini.com/street stainless steel.
  • Product equipped with sigle or double Zhaga 4-Pin connection.
  • Product equipped with Nema 7-PIN Dali Fitting complete with protective cap.
  • The BLE - DALI interface means that all DALI products can be managed via Bluetooth Low Energy (more information).

Colours available for Street

  • 15 Grey
