LED street lighting system: Archilede HP >

LED street lighting system: Archilede HP - Pole-top applications iGuzzini

CONICAL CURVED POLE: available in two configurations with upper and upper/intermediate attachment. POLE WITH ARM: available in two configurations with single and double arm.

POLE-TOP: the Archilede optical assembly can be installed on pole-top position (single, double or triple) in poles with ø 46 to ø 76 mm. Adapter for installation available for poles with ø 102 mm. It can also be installed in intermediate position and on walls.

Municipality of Ponteresina - Switzerland | photo: Paolo Carlini

> <

About the product

Archilede HP (High Performance, Enel Sole by iGuzzini) is fitted with high performance lighting optics that ensure exceptional visual comfort for vehicular traffic (Glare index G4) and for pedestrian urban areas (Glare index G6).

• Street lighting system for use with LEDs.

• Installation on pole-tops, with lateral arms or on tapered poles with attachment diameter ø 46/60/76 mm.

• Die-cast aluminium optical assembly; sodium-calcium sealing glass, 5 mm thick, siliconed to frame.

• Pole-top installation on poles with ending part of ø 76 mm.

• Reflectors in silver aluminium available with 5 different light distributions.

Opti Smart

Archilede is fitted with high performance lighting optics that ensure exceptional visual comfort for vehicular traffic (Glare index G4) and for urban pedestrian areas (Glare index G6).

It is the only pole mounted LED system on the market that is available with class G4 glare intensity and efficiency of 105 lm/W.

Timeless LED Technology

The system is designed so that the LED sources can be updated in line with technological developments (Future Proof). Maintenance is simple and quick both for the optical assembly (replacement time 30 seconds) and for the electrical circuits (replacement time 60 seconds).

Smart Light Control

The driver allows the use of 3 fixed profiles (1/2/3) and one variable profile (4) for different output lumen levels and different powers.

Profile 1 fixed to 350mA
Profile 2 fixed to 450 mA
Profile 3 fixed to 525mA
Profile 4 variable to 350mA

The profiles can also be customised further via USB by including, for example, midnight recognition or decreasing the output lumen levels in each profile.

Product Type

> Pole-top applications

Go to our online catalogue for all the details about this product!

> Archilede HP
