iRound recessed outdoor downlight
Overview
- Luminaire with direct emission for use with LEDs.
- Recessed installation into the ceiling.
- High visual comfort.
- Composed of (circular) optical assembly, frame, lateral component box and outer casing to be ordered separately, if necessary.
- Aluminium alloy optical assembly and frame; sodium-calcium tempered glass, secured to the frame with silicone; 99.96% super-pure aluminium reflectors; the lateral component holder box and top end cap are made of plastic (small body) or aluminium alloy (large body); complete with a silicone internal gasket to guarantee watertightness.
- Outer casing for concrete false ceilings made of black-painted pre-galvanized steel sheet complete with end cap and threaded bar..
- Versions with multiwatt ballasts available.
- Adjustable optics.
- Luminaire reduced height.
- Luminaire ready for pass-through wiring.
- All external screws are A2 stainless steel.
Protection Ratings
-
Class I -
Class II -
IP66
Mechanical Resistance
-
Protected against 2 J shocks
Certifications & Approvals
-
BVB Byggvarube- dömningen -
CCC Pending -
CCC S&E -
CE -
EAC -
ENEC-03 -
UK Conformity Assessed -
BIS -
QCERT
Key Features
-
Multiwatt ballasts -
Luminaire reduced height -
Opti Beam high-performance reflectors -
Compatibility with DALI protocol -
Pass-through wiring -
Adjustable optics
