Lun-Up Evo in-ground
Overview
- Floor/ground-mounted recessed luminaire intended for use with power monochrome LED light sources.
- Available with Flood and Wide- Flood optics.
- Recessed installation on ground/ floor using the specific frame casing.
- Comprising a body and frame casing to be ordered separately, with a 1/4 circle shape.
- Body in high performance, black PPS (polyphenylene sulphide) thermoplastic material; tempered sodium-calcium sealing glass with customized black silk-screen printing, 8 mm thick, mounted with silicon on a stainless steel plate with self-securing inserts; the glass + plate unit combines perfectly with the body thanks to stainless steel nuts and a silicone gasket insert.
- Supplied with high definition “OptiBeam” reflectors in metallised thermoplastic material with Flood and Wide- Flood optics.
- Monochrome version with 24Vdc electronic circuit, neutral white or warm white LED and power supply to be ordered separately.
- In the lower compartment, the product is complete with a plastic PG9, multipolar cable L = 350mm with anti-transpiration device with quick coupling suitable for cables having a diameter D = 7 ÷ 13mm; a 3-way male/female branch connector and IP68 male connector are available as accessories for through-passing wiring.
- Plastic frame for floor/ground installation with top closure cap; the package includes a joint for connecting two or more consecutive frames.
- Product-frame connection is ensured by two captive screws in A2 stainless steel.
- Contact temperature <40 °C.
- Static load resistance: 2000Kg.
- All screws used are in A2 stainless steel.
- The BLE - DALI interface means that all DALI products can be managed via Bluetooth Low Energy (more information).
Protection Ratings
-
Class III -
IP67
Mechanical Resistance
-
Protected against 5 J shocks -
Static load resistance 1500kg
Certifications & Approvals
-
CE -
EAC -
ENEC-03 -
UK Conformity Assessed -
BIS -
QCERT
Key Features
-
Static load resistance -
RGB versions -
Opti Beam high-performance reflectors -
Pass-through wiring
