iPro 132mm
Overview
- Direct light luminaire for use with LED.
- Installation on wall with bracket, surface and floor.
- Optical assembly and front frame made of die-cast material; hardened transparent sodiumcalcium safety glass, 5 mm thick, siliconed to frame.
- Bracket made of extruded aluminium with silk-screened graduated scale for easier aiming operations.
- Internal silicone gaskets to guarantee water tightness.
- Circular and asymmetrical longitudinal reflectors made of 99.93% superpure aluminium subjected to anodic oxidation process and polishing.
- Asymmetrical transversal reflector made of 99.85% superpure aluminium subjected to anodic oxidation process.
- LED versions available with TW (Tunable White) compatible with lighting management systems.
- High level of light output.
- Graduated scale and mechanical aiming lock.
- Luminaire ready for pass-through wiring.
- Class II luminaire, set up for class I.
- All external screws are in A2 stainless steel.
Protection Ratings
-
Class II -
IP66
Mechanical Resistance
-
Protected against 2 J shocks
Certifications & Approvals
-
CE -
EAC -
ENEC-03 -
UK Conformity Assessed -
BIS -
QCERT
Key Features
-
Luminaire angle relative to the horizontal plane -
Luminaire rotation about the vertical axis -
Graduated scale and mechanical aiming lock -
Opti Beam high-performance reflectors -
Compatibility with DALI protocol -
Compatibility with DMX protocol -
Pass-through wiring -
0-10 volt -
Tunable White versions
