iPro 192mm wall mounted
Overview
- Luminaire for use with metal halide, sodium vapour and LEDs.
- Can be wall-mounted using a special base.
- Composed of optical assembly and component-holder with base for ceiling-mounted installation.
- Made of die-cast aluminium coated with acrylic liquid paint with high resistance to weather agents and UV radiation; hard sodium-calcium safety glass, 5 mm thickness; frame joined to optical assembly by means of two AISI 304 stainless steel M5 captive screws and steel safety cable.
- Internal silicone watertight gaskets.
- Luminaire ready for pass-through wiring.
- Class II luminaire, set up for class I.
- All external screws are in A2 stainless steel.
Protection Ratings
-
Class I -
Class II -
IP66
Mechanical Resistance
-
IK07 - Protected against 2 J shocks
Certifications & Approvals
-
BIS pending -
CE -
EAC -
ENEC-03 -
ENEC pending -
UK Conformity Assessed -
BIS -
Q-CERT -
TISI
Key Features
-
Luminaire angle relative to the horizontal plane -
Luminaire rotation about the vertical axis -
Graduated scale and mechanical aiming lock -
RGB versions -
Opti Beam high-performance reflectors -
Compatibility with DALI protocol -
Compatibility with DMX protocol -
Pass-through wiring -
0-10 volt -
Tunable White versions
