Wow wall mounted 620x307mm

All Wow

Lighting Effects

Product Details

  • Urban lighting system intended for use with LED light sources.
  • Installation on poles with pole-tops using lateral arms or on whip-type poles with ø 46/60/76 mm diameter connection.
  • Reflectors in silver aluminium.
  • Optical compartment in die-cast aluminium; hot dip galvanised steel tubular arms; sodium-calcium sealing glass, 5 mm thick, siliconed to frame that closes the LED compartment with a hinge and 2 screws.
  • No upwards dispersion of the luminous flux.
  • This luminaire is in the “Exempt Group” (no risk linked to infrared, blue light and UV radiation) in accordance with EN 62471:2008.
  • Adjustable optical compartment.
  • High visual comfort.
  • No photo-biological risks .
  • High yield optics (Opti Smart Reflector) with uniform light distribution.
  • The luminaire is fully programmable as regards luminous flux emission through the MY92 device.
  • DALI driver compatible with remote management systems.
  • Overvoltage protection: 10kV in Common Mode (CM), 6kV in Differential Mode (DM).
  • An active control system changes the current intensity in order to maintain the lifespan of the LEDs even under extreme thermal conditions.
  • Replaceable LED group.
  • Replaceable driver and power supply unit.
  • All external screws used are in A2 stainless steel.

Colours available for Wow wall mounted 620x307mm

  • 04 Black
  • 15 Grey
  • F5 Rust brown
  • 01 White

Do you want to know more?

Click to access our Contact Us page where you can send us an enquiry.

Make Enquiry

5 year product warranty included
